    Cellarator CX (E) R407C

    The innovative CXE Cellarator split range is designed to help the licensed trade maintain a cooled environment more effectively than ever before.
    With its revolutionary one piece moulded body, impregnated with an anti-bacterial additive, the Cellarator is ideal for cellar cooling, food preparation areas and other areas requiring controlled temperatures down to 4°C.
    Provides consistent temperature control combined with economy, ease of maintenance, flexible positioning, hygiene, safety and reliability.

    Specification

    • Capacity range from 2.3 - 6.8kW
    • Now available as a pump down option in five sizes including CXE90
    • Long pipe runs up to 80m (50m for CKC/DCU+ 20 & 30)
    • The unit controls temperatures down to 4°C (dependent upon system match)
    • De-ice stat is standard on CXE electronic units
    • Antibacterial agent added to the chassis during the moulding process for complete mold protection throughout the material
    • 6 fins-per-inch brewery specification heat exchanger
    • Mounting brackets suitable for both wall and ceiling mounting and a waterproof power switch
    • Direct access to the electrics at the front of the unit
    • ABS drain tray incorporating standard 22mm OD fitting drain stub
    • Easy to install electric heater kit with factory fit option Outdoor condensing units incorporating a low pressure switch, HP switch and low ambient start as standard
    • Optional ducted condensing units for where external installations are not feasible
    • Stylish design chassis and rounded corners for safety
    • The innovative CXE Cellarator split system is designed to help the licensed trade maintain a cooled environment more effectively than ever before
    • With its revolutionary one piece moulded body, impregnated with an anti-bacterial additive, the CX(E) is ideal for cellar cooling, food preparation areas and any areas requiring controlled temperatures down to 4°C
    • The Cellarator provides consistent temperature control with economy, ease of maintenance, flexible positioning, hygiene, safety and reliability
    • Matched with CKC or DCU(+) condensing units, which are supplied with a nitrogen holding charge
    • The CXE Low Temperature is for more challenging environments

    Additional Features

    • CXE 30 - 18kg CXE 40 - 18kg
    • CXE 50 - 20kg CXE 70 - 23kg
    • CXE 30 - 70 - 467mm x 845mm x 320mm
