Cellarator CX (E) R407C

Specification

• Capacity range from 2.3 - 6.8kW
• Now available as a pump down option in five sizes including CXE90
• Long pipe runs up to 80m (50m for CKC/DCU+ 20 & 30)
• The unit controls temperatures down to 4°C (dependent upon system match)
• De-ice stat is standard on CXE electronic units
• Antibacterial agent added to the chassis during the moulding process for complete mold protection throughout the material
• 6 fins-per-inch brewery specification heat exchanger
• Mounting brackets suitable for both wall and ceiling mounting and a waterproof power switch
• Direct access to the electrics at the front of the unit
• ABS drain tray incorporating standard 22mm OD fitting drain stub
• Easy to install electric heater kit with factory fit option Outdoor condensing units incorporating a low pressure switch, HP switch and low ambient start as standard
• Optional ducted condensing units for where external installations are not feasible
• Stylish design chassis and rounded corners for safety
• The innovative CXE Cellarator split system is designed to help the licensed trade maintain a cooled environment more effectively than ever before
• With its revolutionary one piece moulded body, impregnated with an anti-bacterial additive, the CX(E) is ideal for cellar cooling, food preparation areas and any areas requiring controlled temperatures down to 4°C
• The Cellarator provides consistent temperature control with economy, ease of maintenance, flexible positioning, hygiene, safety and reliability
• Matched with CKC or DCU(+) condensing units, which are supplied with a nitrogen holding charge
• The CXE Low Temperature is for more challenging environments

Additional Features

• CXE 30 - 18kg CXE 40 - 18kg
• CXE 50 - 20kg CXE 70 - 23kg
• CXE 30 - 70 - 467mm x 845mm x 320mm
